TOPDON TC004 thermal camera front angle view handheld infrared imaging device for electrical and building inspections

TC004

$299.00
$299.00
Sale Sold out

Upgraded Handheld Thermal Imaging Camera 256x192 Resolution

The TC004 is a professional thermal inspection tool built for fast, everyday jobsite use. Its 3.5-inch display and TISR-supported imaging deliver clear thermal visuals, while built-in WiFi enables a streamlined workflow for electrical, building, and mechanical inspections.

  • Have questions? Ask an expert
View full details
4.8
  • TOPDON TC004 thermal camera front angle view handheld infrared imaging device for electrical and building inspections
  • TOPDON TC004 thermal imaging camera front display screen showing TCView interface for real time thermal analysis
  • TOPDON TC004 infrared thermal camera rear view showing dual lens and sensor layout for precise temperature measurement
  • TOPDON TC004 handheld thermal imager side profile ergonomic design for industrial and HVAC inspection use
  • TOPDON TC004 infrared camera back housing with product label and rugged design for jobsite inspections
  • TOPDON TC004 thermal camera top view showing sensor opening and USB port for data transfer and charging
  • TOPDON TC004 thermal imaging device bottom view with mounting point and durable construction
  • TOPDON TC004 handheld infrared camera angled rear view showing grip and dual lens system for inspection accuracy
1 9

Features

  • Larger Display. Clearer Decisions.
  • Sharp, Clear Thermal Images
  • Laser Pinpointed Inspection Accuracy
  • Expanded Storage for Thorough Documentation
  • Flexible Connectivity for Fast Reporting
Discover all product features below

Warranty & Updates

  • 1 Year Warranty

Resources

  • WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
Thermal Hardware
System
Operating System
Battery Capacity
Display Screen
Operating Voltage
Charging Time
Battery Life
ROM
LED Flashlight
Thermal Imaging
Calibration Temperature Measurement Distance
Identification Distance
Recognition Distance
Detection Distance
Measurement Accuracy
Infrared Light Resolution
Focal Range
FOV
Spectral Range
NETD
Temperature Resolution
Frame Rate
AI Algorithm
Image Algorithm
Thermal Functions
Measurement Range
Professional Function
Digital Zoom
Image Modes
Measuring Modes
Video Recording
Video Transfer via USB
Wi-Fi
PC-Based Analysis Software
Visible Light Camera Lens
Pseudo Color Bar
High/low temperature alarms
Automatic Power-off Time
Temperature Units
Physical & Environmental
Working Temperature
AC Cable Length
Dimensions
Warranty
Operating Temperature
Tripod Screw Hole
Drop, Impact, and Vibration
IP Rating
Certifications
Gross Weight (g)
Device Weight (g)
Package Size (mm)
Cycle Life
Weight
Storage Temperature
Housing Protection
Standard Cable Length
Optional Cable Length
Enclosure
Cable
Altitude
Operating Altitude
Cable Length
Package Dimensions
Certification
Languages
Software Languages
User Manual Languages
Languages
Multi-Lingual Interface (22+ Languages)
Supported Languages for APK
Updates
Updates
Upgrade Method
Subscription
Renewal
Functional Expansion

Linux
iOS/Android/Windows Devices/Standalone use
5000mAh
3.5 inch, 640x480 screen
5V
4h
12h
64GB eMMC

0.2m~5m
0.1~40m
40~80m
80~320m
±2°C or ±2%
256x192 (512x384 TISR)
3.2mm
56°X42°
8 – 14μm
<40mK
0.1℃
25Hz

-20 to 550℃ (-4 to 1022℉)
Industrial
1x/2x/4x
Thermal Imaging
Center spot/hot spot/cold spot
Supports image analysis with PC
5 colors (white hot, black hot, iron, rainbow,dark red)
5 mins, 10 mins, 20 mins, Off
Celsius, Fahrenheit, Kelvin





-10°C to +50°C
2.0m, impact 25g (IEC 60068-2-27), vibration 2.5g (IEC60068-2-6)
IP54
UN38.3/DGM/CE/FCC/RoHS/UKCA
1010
520
276*160*124
















13 languages (English, Traditional Chinese, Korean, Japanese, French, Spanish, Italian, Portuguese, German, Polish, Russian, Hungarian, Turkish)



Connect to PC for updates




Larger Display. Clearer Decisions.

The TC004 features a 3.5-inch display that provides a wider and more comfortable viewing experience, making it easier to identify hotspots and temperature differences during daily inspections.

Sharp, Clear Thermal Images

With a 256×192 infrared resolution (TISR-enhanced up to 512×384), the TC004 captures detailed thermal images that help you detect temperature variations and make confident decisions on the first pass.

Laser Pinpointed Inspection Accuracy

A built-in red laser pointer marks the measurement area, making it easier to align thermal images with the actual target and locate anomalies during inspections.

Expanded Storage for Thorough Documentation

Equipped with 64GB of built-in storage, the TC004 allows you to store thousands of images and videos, supporting thorough documentation throughout the workday without interruptions.

Flexible Connectivity for Fast Reporting

Integrated Wi-Fi connects to the TopInfrared mobile app, while a USB connection supports file transfer and analysis through TopView PC software. Sync files quickly, perform thermal analysis, and generate professional inspection reports more efficiently.

Long Runtime for Extended Inspections

Powered by a 5,000 mAh battery, the TC004 delivers up to 8.5 hours of continuous operation and fully recharges in just 2 hours, supporting extended inspections with minimal downtime.

Built for Demanding Inspection Environments

Built for real-world environments, the TC004 features IP54-rated protection against dust and splashes, 2-meter drop resistance, and an integrated LED light to improve visibility in dark or confined inspection areas.
